BRAKE HARDWARE
BRAKE REPAIR KITS
E-10244 MEGA PLUS EATON 16-1/2” “ES-II” “EXTENDED SERVICE” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10198
Retainer Spring
For use with New “ES-II”, No-Tab
Shoe with Retainer Spring holes
in web. IMPORTANT NOTE: Install
Retainer Springs with coil end up.
Can only be used with Eaton “ES”
Camshafts.
REPLACES:
Eaton 314147
Dana/Spicer 631A
Haldex CQ65477
Dana/Spicer HK61
Dana/Spicer HK61SD
Dana/Spicer HK61XLS
Leland K375
Meritor R507064
2 1
E-10197
Return Spring
3 2
E-5477
Roller
4 2
E-5478
Roller Retainer
5 1
E-3887
Anti-Seize Compound
E-10244S STOPMATE PLUS EATON 16-1/2” “ES-II” “EXTENDED SERVICE” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10198
Retainer Spring
For use with New “ES-II”, No-Tab
Shoe with Retainer Spring holes
in web. IMPORTANT NOTE: Install
Retainer Springs with coil end up.
Can only be used with Eaton “ES”
Camshafts.
REPLACES:
Eaton 314147
Dana/Spicer 631A
Sirco ES2
Meritor R507064
2 1
E-10197
Return Spring
3 2
E-5477
Roller
4 2
E-5478
Roller Retainer
E-11319 STOPMATE PLUS EATON 16-1/2” “ES-II” “EXTENDED SERVICE” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10198
Retainer Spring
For use with New “ES-II”, No-Tab
Shoe with Retainer Spring holes
in web. IMPORTANT NOTE: Install
Retainer Springs with coil end up.
Can only be used with Eaton “ES”
Camshafts.
REPLACES:
Sirco K4
2 1
E-10197
Return Spring
E-4709ES2-N STOPMATE EATON 16-1/2” “ES-II” “EXTENDED SERVICE” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
NSS*
Roller
Stopmate version of E-10244.
For use with the following Brake
Shoes: E-10272 (7”), E-10273 (8-
5/8”) Can only be used with Eaton
“ES” Camshafts. Also available
bagged as part number
E-4708ES2-B.
REPLACES:
Haldex CQ65477
Sirco ES2
Leland K375
Sirco K4
2 2
NSS*
Roller Retainer
3 1
NSS*
Return Spring
4 2
NSS*
Retainer Spring
*Not Sold Separately
