BRAKE HARDWARE
BRAKE REPAIR KITS
E-9141 MEGA PLUS EATON 15” 6” “ES” “REDUCED ENVELOPE” FRONT AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-5477
Roller
For use with the following Brake
Shoe: E-9140 (6” )
REPLACES:
Dayton/Batco 08104300
Eaton 823141
Haldex CQ66947
Sirco ES3
Leland K356
Meritor R507086
2 2
E-5478
Roller Retainer
3 2
E-9037
Return Spring
4 2
E-2767
Retainer Spring
E-2713 MEGA PLUS WAGNER 15” 6” and 7” DRIVE AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-1337
Anchor Pin
For use with the following Brake
Shoe: E-2712 (7”)
REPLACES:
Dayton/Batco 081084
Dayton/Batco 08108400
Dana/Spicer 60A
Haldex 67314
Haldex CQ67314
Wagner F33186
Dana/Spicer HK53
Leland K132
Meritor R507070
2 4
E-801
Lock Ring
3 2
NSS*
Roller
4 2
NSS*
Roller Pin
5 1
E-980
Return Spring
6 4
E-1269
Anchor Pin Seal
E-9039 MEGA PLUS EATON 15” 8-5/8” “ES” “REDUCED ENVELOPE” DRIVE AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-5477
Roller
For use with the following Brake
Shoe: E-9036 (8-5/8”)
REPLACES:
Dayton/Batco 08104330
Eaton 815626
Haldex CQ66948
Sirco ES4
Leland K358
Meritor R507083
2 2
E-5478
Roller Retainer
3 1
E-9038
Return Spring
4 2
E-2767
Retainer Spring
E-4692 MEGA PLUS MERITOR 16-1/4” “T” SERIES FRONT BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3421A
Roller
REPLACES:
Dayton/Batco 081108
Dayton/Batco 08110800
Dayton/Batco 081109
Dayton/Batco 08110900
Dana/Spicer 521A
Haldex 66923
Haldex CQ66923
Dana/Spicer HK52
Leland K286
Leland K362
Meritor KIT9424
Dana/Spicer TA521A
2 2
NSS*
Anchor Pin
3 1
E-757
Return Spring
4 2
E-3426
Lock Ring
5 2
E-1106
Anchor Pin Lock Washer
6 2
E-1120-1
Shoe Clip
*Not Sold Separately
