BRAKE HARDWARE
BRAKE REPAIR KITS
E-5481A MEGA PLUS EATON 16-1/2” “ES” “EXTENDED SERVICE” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-1418
Retainer Spring
For use with the following Brake
Shoe: E-5480 (7”). Can only be
used with Eaton “ES” Camshafts.
REPLACES:
Dayton/Batco 081148
Dayton/Batco 08114800
Trailmobile 385481
Eaton 5808330
Eaton 5808330B
Dana/Spicer 631A
Dana/Spicer 632A
Dana/Spicer 63A
Haldex CQ65481
Sirco ES1
Dana/Spicer HK62
Dana/Spicer HK63
Dana/Spicer HK63XLS
Leland K295
Meritor R507057
Meritor R507057BK
Meritor R507057BULK
Dana/Spicer TA63A
2 1
E-10197
Return Spring
3 2
E-5477
Roller
4 2
E-5478
Roller Retainer
5 1
E-3887
Anti-Seize Compound
E-9048 MEGA PLUS EATON 16-1/2” “ES” “SEVERE SERVICE” BRAKE WITH CAST SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-9041
Anchor Pin
For use with the following Brake
Shoe: E-9040 (7”)
REPLACES:
Dayton/Batco 081157
Dayton/Batco 08115700
Eaton 810213
Dana/Spicer HK72
Leland K307
Meritor R507084
2 2
E-9042
Set Screw
3 4
E-1113
Washer
4 4
E-801
Lock Ring
5 4
E-9047
Brake Shoe Bushing
6 2
E-919
Anchor Pin Bushing
7 2
E-9043
Roller
8 2
E-9044
Roller Pin
9 2
E-9045
Lock Pin Roll
10 1
E-9046
Return Spring
E-9052 MEGA PLUS EATON 16-1/2” “ES” “SEVERE SERVICE” BRAKE WITH FABRICATED SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
NSS*
Anchor Pin
Contains new Posi-Plus roller.
REPLACES:
Dayton/Batco 081156
Dayton/Batco 08115600
Eaton 812118
Leland E9052
Meritor R507085
2 2
E-9042
Set Screw
3 4
E-1113
Washer
4 4
E-801
Lock Ring
5 2
E-919
Anchor Pin Bushing
6 2
E-11741
Roller
7 2
E-5478
Roller Retainer
8 2
E-747
Spring Retainer
9 1
E-8907
Return Spring
*Not Sold Separately
