Assembly PN
Description
Drum PN
4.06
5.94
8.46
13.19
6 Holes 5/16"-18 UNC.,
6.75 Bolt Circle
N/A
N/A
SAE "K30" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
2133 Series Assemblies
752 / 759
742 / 740
Std. Hub Weight
48 lbs.
006-02133
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8" Drum
54251-01
16.50 9.15
11.25 12.37
M22 x 1.5
2.40
10.64
187
1.73
PRT-00117
006-02133L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 8-5/8" Drum
54251-01
16.50 9.15
11.25 12.37
M22 x 1.5
3.26
10.64
189
1.73
PRT-00118
006-02135
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
2.41
8.91
186
1.68
PRT-00117
006-02135L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
3.26
8.91
188
1.68
PRT-00118
Option "T" - ABS Tone Ring
7.28
PRT-13301
100-Tooth Tone Ring
Part Number
Description
Pitch Diameter
Notes
Fill port option available.
