Assembly PN
Description
Drum PN
4.50
6.94
9.06
275mm (10.83")
6.25 X 8 TPI Threaded
0.39
6.39
SAE "P" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
41045 Series Assemblies
HM518410 / HM518445
HM518410 / HM518445
Std. Hub Weight
0 lbs.
004-41045
Hub Pilot, M22 x 3.97 Stud, 12.25 x 7.5" Drum
54244-01
12.25 9.84
9.00 11.22
M22 x 1.5
2.65
9.43
141
1.79
PRT-00117
004-41045L
Hub Pilot, M22 x 4.82 Stud, 12.25 x 7.5" Drum
54244-01
12.25 9.84
9.00 11.22
M22 x 1.5
3.50
9.43
142
1.79
PRT-00118
Option "T" - ABS Tone Ring
6.77
PRT-00981
80-Tooth Tone Ring
Part Number
Description
Pitch Diameter
