Assembly PN
Description
Drum PN
4.50
5.95
8.07
11.25
6 Holes 5/16"-18 UNC,
6.75 Bolt Circle
0.51
6.50
SAE "P" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
41043 Series Assemblies
HM518410 / HM518445
HM518410 / HM518445
Std. Hub Weight
48 lbs.
004-01043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
2.60
8.86
156
1.28
PRT-00117
004-01043L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
3.45
8.86
158
1.28
PRT-00118
004-01048
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8 5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
2.52
9.62
165
1.28
PRT-00117
004-01048L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 8 5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
3.37
9.62
165
1.28
PRT-00118
004-21043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum Bal
60000-018
16.50 7.56
8.78 10.56
M22 x 1.5
2.60
8.86
150
1.28
PRT-00117
004-21043L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum Bal
60000-018
16.50 7.56
8.78 10.56
M22 x 1.5
3.45
8.86
152
1.28
PRT-00118
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
Notes
Fill port option available.
