Assembly PN
Description
Drum PN
3.03
4.29
7.08
11.25
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.49
6.50
SAE "FL" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
51005 Series Assemblies
6420 / 6461A
552A / 555S
Std. Hub Weight
61 lbs.
005-51005L
Hub Pilot, M22 x 4.25 Stud, 16.5 x 6" Drum Bal
54248-018
16.50 6.41
8.78
9.76
M22 x 1.5
2.44
4.86
170
4.90
PRT-00122
005-51005X
Hub Pilot, M22 x 4.82 Stud, 16.5 x 6" Drum Bal
54248-018
16.50 6.41
8.78
9.76
M22 x 1.5
3.01
4.86
169
4.90
PRT-00118
Option "T" - ABS Tone Ring
6.92
PRT-00935
100-Tooth Tone Ring
Part Number
Description
Pitch Diameter
