35 / 105
34
Copyright © 2015 KIC LLC
Assembly PN
Description
Drum PN
4.50
5.95
8.07
335mm (13.19")
6 Holes M31 x 1.25
UNC, 6.50 Bolt Circle
0.44
6.50
SAE "P" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
40310 Series Assemblies
HM518410 / HM518445
HM518410 / HM518445
Std. Hub Weight
61 lbs.
004-40310
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
3.13
8.81
178
1.79
PRT-00117
004-40310L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
54250-01
16.50 7.44
11.25 10.59
M22 x 1.5
3.13
8.81
178
1.79
PRT-00118
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
Notes
Fill port option available.
