STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 2
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
Steering Knuckle King Pin Kits
revision date 11/2012
CHEVROLET
CHEVROLET
Top Kick - C-Series
6000#(FN9)
88936084
A 1.234 x 6.78
K60R
ST70-3
7000# FM7
88936119
B 1.499 x 7.15
K70R
70.070.18 50.070.18 ST70-28
8000# FM8
88936011
B 1.499 x 7.50
K80R
70.080.18 50.080.18 ST70-28
10000# FM6
B 1.794 x 10.40
K121R
8100#(FL1)
1990 to date
12540328
15619560
G 1.614 x 8.00
K80G
11
9000#
11000#(FL2)
12000#(FS7)
1990 to date
12540329
15619561
G 1.889 x 9.20
K110G
11
Top Kick - T-Series
14000#(FH0)
14500#(FL3)
14600#(FSD)
1990 to date
12540330
15619562
G 1.889 x 9.62
K120G
11
EFA18F3
16000#
12541348
3927942
A 1.872 x 9.96
K180E
70.180.05 50.180.05 ST70-23
2 1/2 Ton - C70, C7D,
H70, J70,
R70, S70, S7T, T70, W70
7000#(F-070)
1963 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000#(F-090)
1962 to date
2321013
2431372
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000#(F-110)
1962-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#(F-120)
1966-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#(F-120D)
1975 to date
8885621
B 1.745 x 9.37
K121G
7
70.121.07
7
50.121.07
7
FF-932
13200#
15510849
B 1.794 x 10.39
K931L
70.931.12 50.931.12 ST70-7
FG-943
14600#
B 1.794 x 10.39
KG931R
77.931.18 57.931.18 ST70-7
18000#(FL-901)
1971 to date
2452865
B 1.999 x 10.90
KH901L
78.901.12 58.901.12
2 1/2 & 3 Ton - A80,
C80,E80,
H80, J80, L80, M80, N80,
Q80
7000#(F-070)
1963 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000#(F-090)
1962 to date
2321013
2431372
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000#(F-110)
1962-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#(F-120)
1966-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#(F-120D)
1975 to date
8885621
B 1.745 x 9.37
K121G
7
70.121.07
7
50.121.07
7
18000#(FL-901)
1971 to date
2452865
B 1.999 x 10.90
KH901L
78.901.12 58.901.12
3 1/2 Ton - D90, F90,
H90, J90, M90, T90, W90 9000#(F-090)
1970 to date
2321013
2431372
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
12000#(F-120)
1970-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#(FE-900)
1970-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
continued
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
