109 / 348
DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
107
1.74
5.50
4.35
1.74
LED
44
®
Series
Dome
Sealed
54 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v, 0.5 amp,
100 lumens
Kit components:
44042C grommet kit:
1 - 44207C lamp
1 - 40700 grommet
1 - 94789 plug
44046C flange kit:
1 - 44237C lamp & flange
1 - 94789 plug
• Popular in trailer & body applications
• 85% reduction of load on electrical
system allows more power for other
vehicle requirements
• Virtually impervious to shock & vibration,
a major cause of failure for lamps with
incandescent bulbs
44042C Clear grommet kit
44046C Clear gray flange kit
44237C Clear lamp & gray flange
44207C Clear lamp
See above & page 106
40
®
Series Dome
Sealed
Material:
• Polycarbonate lens & housing
• ABS flange
Light Source:
• Designed at 12.8v, 1.44 amp,
21 cp
Kit components:
40003 grommet kit:
1 - 40203 lamp
1 - 40700 grommet
1 - 94992 plug
40023 gray flange kit:
1 - 40223 lamp & flange
1 - 94992 plug
• Shock mounted bulb to extend lamp life
• Uses standard PL-2 connection
40003 Clear grommet kit
40023 Clear flange kit
40203 Clear lamp
40223 Clear lamp & gray flange
40227 Clear lamp for exterior use
2.150
5.500
4.460
5.500
2.000
1.040
.430
Flange mount
Grommet mount
40023
40003
40
®
Series Dome
Clear Back
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 12.8v, 1.44 amp,
21 cp
Kit components:
40011 grommet kit:
1 - 40211 lamp
1 - 40703 grommet
1 - 94961 plug
• Features clear back housing
• Sealed polycarbonate lens & housing
• Grommet kit features flush mounting in a 4-1/2”
40011
Clear grommet kit
40211
Clear lamp
5.500
2.000
1.040
.430
Grommet mount
40011
