108 / 348
DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
106
4”
5.6”
Increase daytime interior lighting
in your trailer without the addition
of supplemental lighting products.
Sky-Lite
Material:
• Polycarbonate lens
• Peel-and-stick adhesive gasket
Additional Specifications:
• Fits a 4” (4.00” +/- 0.05”)
diameter hole
• Gaskets are designed at
three separate thicknesses to
accommodate:
0.05” Aluminum Sheeting
0.31” Composite Panels
0.25” Composite Panels
• Provides trailer access to external sunlight to
assist in lighting up trailer interior, without the
need for additional power or wiring
• Snap-in design and peel-and-stick adhesive
gasket provide an easy to install lens that
keeps water out
• Application surface that comes in contact with
the gasket adhesive should be cleaned with a
50/50 isopropyl alcohol and water mixture before
installation to remove any dirt or oils
• Gasket is to be pressed on around its entire
perimeter to ensure complete adhesion and seal
40270C Sky-Lite for 0.05” Aluminum Sheets
40271C Sky-Lite for 0.31” Composite Panels
40275C Sky-Lite for 0.25” Composite Panels
1.25”
5.90”
5.37”
1.25”
5.90”
5.37”
LED
Super 44
®
Surface
Mount Dome
Sealed
6 Diode Pattern
Material:
• Polycarbonate lens & housing
• Hardwired, .180 bullet molded
terminals
• 2 - 18 ga. blunt cut wire
Light Source:
• 6 Light Emitting Diodes (LEDs)
• Designed at 13.5v,
0.5 amp, 380 lumens
• Surface mount design eliminates the need for large hole cutouts in trailer ceiling
• Available with integrated on/off switch as well as externally controlled version
• Lens design recesses lens into housing, to prevent damage from impact
• Not affected by cold temperatures, providing flicker-free lighting with a faster
start-up time
• Recommend 3 #10 machine screws for mounting, with torque of 15-18 in-lbs.
44438C Clear lamp w/switch
44439C Clear lamp
LED Super 44
®
Dome
Sealed
6 Diode Pattern
Material:
• Polycarbonate lens, housing,
flange or housing & flange
• Hardwired, .180 bullet molded
terminals
• 2 - 6-1/2” 16 ga. wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v,
0.500-0.575 amp, 360 lumens
Recommended Accessories:
• Mounting: Pages 259-261
• Low profile lamp, approximately 1” deep for where space is at a premium
• Same 6 diode pattern used in Truck-Light Stop/Turn/Tail and Back-Up
• Designed to operate in extremely cold temperatures
• Broad light pattern with approximately 360 lumens of light output
• U.S. Registered TM #3483147
44308C Clear lamp
44339C Clear lamp & gray flange
