PEDESTAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
48
Dual Face
GM Turn Signal
Horizontal Mount
Bulb Replaceable
Material:
• Acrylic lens
• ABS housing
Light Source:
• Bulb: #1156 signal
• Bulb: #1895 marker
• Bulb: #1816 park
Replacement Parts:
• 9063 red lens
• 9080A yellow marker lens
FMVSS:
• I6,P2,P,A
Navistar Turn Signal
Horizontal Mount
Bulb Replaceable
Material:
• Acrylic lens
• Die cast housing
• 16 gauge wire
Light Source:
• Bulb: #1816 park
• Bulb: #1156 signal
Replacement Parts:
• 8960 red lens
• 96195 lens gasket
4.38
1.00
4.75
1/2"-20
2.44
Vertical/Horizontal
Mount Turn Signal
Bulb Replaceable
Material:
• Acrylic lens
• Die cast housing
• 16 gauge wire
Light Source:
• Bulb: #1816 park, #1156 signal
Replacement Parts:
• 8960 red lens
FMVSS:
• I6,S2,T,P2
• Mounts left or right, horizontally or vertically
• Mounting hardware for stud or pedestal
installation
955
955
Red/Yellow w/side marker
clearance lamp
• Replaces GM #694627
(LH) & #694628 (RH)
• Mounts on 3.20” centers
& connects with 2 spade
terminals
• Unique GM harness
connector (harness not
available from Truck-Lite)
4854 Red/Yellow, RH
4855 Red/Yellow, LH
2.25"
1.625"
2.375"
3.375"
2.625"
4.375"
• Receptacle type connector
• Mounting bracket included
956AA Yellow/Yellow w/o parking lamp, Navistar
#582779C91
957AA Yellow/Yellow w/parking lamp, Navistar
#582780C91
956AA
Dual Face
GM Turn Signal
Horizontal Mount
Bulb Replaceable
Material:
• Polycarbonate lens
& housing
Light Source:
• Bulb: #1157
FMVSS:
• I6,P
• GM #2029217
• Mounts on 3.20” centers &
connects with 3 spade terminals
• Unique GM harness connector
(harness not available from
Truck-Lite)
4872AA Yellow/Yellow
