PEDESTAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
50
4.62
1/2"-20
4.70
1.88
3.00
4.74
4.92
2.40
1/2-20STUD
LED
Double Face
Pedestal Lamp
Square Sealed
24 Diode Pattern
Material:
• Polycarbonate lens
• Chrome plated housing
Light Source:
• Light Emitting Diodes (LEDs)
• Yellow/yellow designed at
12.8v; major 0.48 - 0.64 amp
• Red/yellow designed at
12.8v; major 0.24 - 0.53 amp;
minor 0.06 - 0.073
FMVSS:
• Red/Yellow: I6
• Yellow/Yellow: I6,P2
• 24 diode pattern
• Chrome plated housing
2752 Yellow/Yellow w/side
marker clearance
lamp
2753 Red/Yellow roadside
2756 Red/Yellow curbside
4801
Dual Face
Turn Signal
Vertical Mount
Bulb Replaceable
Material:
• Acrylic lens
• Black or chrome plated
polycarbonate housing
• 16 gauge wire
Light Source:
• Bulb: #1156 turn signal
• bulb: #1895 marker
Replacement Parts:
• 9063 red lens
• 9063A yellow lens
• 9080A yellow marker lens
FMVSS:
• I6,A,P2
• Black housed version is
a popular Western Star
replacement
• Chrome housed version is
a popular replacement for
Volvo & Peterbilt
4800 Red/Yellow,
black housing
4801 Red/Yellow,
chrome housing
4.70
2.00
4.80
1.40
2.80
5/16"-18
Dual Face
Turn Signal
Vertical Mount
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Bulb: #1156 signal
• Bulb: #1895 marker
Replacement Parts:
• 9083 red lens kit
• 9080A yellow marker lens kit
FMVSS:
• I6,A,P2
4805AY116
Red/Yellow, LH
4805AY117
Red/Yellow, RH
• Freightliner #A06-18900-000 (LH), #A06-18900-001 (RH)
• Includes OEM 49” harness that mates with truck
harness – simplifying replacement
• Mounting pad included
• Two 5/16” studs on 2” centers
4.70
2.00
4.80
1.40
5/16"-18
2.80
Dual Face
Turn Signal
Vertical Mount
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Bulb: #1156 signal
• Bulb: #1895 marker
Replacement Parts:
• 9079 red lens
• 9079A yellow lens
• 9080A yellow marker lens kit
FMVSS:
• I6,A,P2
• 4805AAY115 includes OEM 7” harness that mates with
truck harness – simplifying replacement
• 4805AAY118 included 75” OEM mating harness
4805AAY115
Yellow/Yellow, black housing,
Freightliner #681-822-0020
4805AAY118
Yellow/Yellow, black housing,
Freightliner #681-822-0120
4805AAY115
4805AY116
