PEDESTAL LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
49
Dual Face
Turn Signal
Horizontal Mount
Bulb Replaceable
Material:
• Acrylic lens
• Polycarbonate housing
• 16 gauge wire
Light Source:
• Bulb: #1156 signal
• Bulb: #1895 marker
Replacement Parts:
• 9063 red lens
• 9063A yellow lens
• 9080A yellow marker lens
FMVSS:
• I6,P,P2,A
LED
Double Face
Pedestal Lamp
2/24 Diode Pattern
Material:
• Polycarbonate lens
• Chrome plated housing
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 12.8v,
Major 0.24 - 0.53 amp
Minor 0.06 - 0.073 amp
FMVSS:
• I6
7.00
5.00
4.70
2.38
2.00
• 24 diode pattern (per side)
with chrome plated housing
• Double-stud mount
2758 Red/Yellow, curbside
2759 Red/Yellow, roadside
4.63
2.00
4.84
1.18
3.10
5/16-18
4.75
2.37
1/4 – 20
2.00
5.06
Universal
Dual Face
Turn Signal
Bulb Replaceable
Material:
• Acrylic lens
• ABS housing
• 16 gauge wire
Light Source:
• Bulb: #1157
Replacement Parts:
• 8938 red signal lens
• 8938A yellow signal lens
FMVSS:
• I6,A,P2,S2,T
• Includes separate ground
wire for installation
4742 Red/Yellow, flat
surface mount,
vertical mount
4754 Red/Yellow, flat
surface mount,
horizontal mount
4742
4754
Universal Dual Face
Turn Signal
Vertical Mount
Bulb Replaceable
Material:
• Acrylic lens
• Chrome plated
polycarbonate housing
• 16 gauge wire
Light Source:
• Bulb: #1157
Replacement Parts:
• 9063A yellow lens
• 9080A S/M lens
FMVSS:
• I6,P,A,P2
• Kenworth #K-256-D-324
• Plugs into Kenworth
harness connector &
includes terminated wire
4874AY101 Yellow/Yellow,
chrome housing
w/harness
4.63
1/2"-20
4.64
2.00
3.12
4.50
2.00
2.75
6.25
5/16"-18
Dual Face Turn Signal
Vertical Mount
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Bulb: #2356
Replacement Parts:
• 9079 red lens
• 9079A yellow lens
• 9080A yellow marker lens kit
• 9260 harness
FMVSS:
• I6
• Navistar #444660C91 (left),
659C91 (Right)
• Keyed plug-in receptacle
accepts OEM harness
4842 Red/Yellow,
black housing
81331 Yellow/Yellow,
black housing
4842
• GM #677914
4810 Red/Yellow,
black housing
