64
LED
30
®
Series
2” Sealed
2 or 3 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at .05 amp
Kit Components:
30050R/Y 12v grommet kits:
1 - 30250R/Y 12v amp
1 - 30700 grommet
1 - 93745 plug
30051R/Y gray flange kit:
1 - 30251R/Y lamp & flange
1 - 93745 plug
30055R/Y 10-30 grommet kit:
1 - 30255R/Y 10-30v lamp
1 - 30700 grommet
1 - 93745 plug
Recommended Accessories:
• Mounting: Pages 253-255
• Plugs: Pages 225-228
FMVSS:
• P2,P3
.96
2.01
• OmniVolt® universal lighting
products address increasing
vehicle power demands by
operating equally in electrical
systems that range from 10 to
30 volts
30250R
30251Y
30271Y
LED Grommet Kits
30050R Red, 12v
30050Y Yellow, 12v
30055R Red, 10-30v
30055Y Yellow, 10-30v
LED Lamp
30250R Red, 12v
30250Y Yellow, 12v
30255R Red, 10-30v
30255Y Yellow, 10-30v
LED Gray Flange Kits
30051R Red, 12v
30051Y Yellow, 12v
LED Lamp & Gray Flange
30251R Red, 12v
30251Y Yellow, 12v
LED Lamp & Flange w/ABS logo
30271Y Yellow, 12v
3050
2.03
.866
.704
2.93
.956
2.28
LED
2” Round
1-10 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LED)
• Designed at 13.5v, 0.05 amp
Recommended Accessories:
•Mounting: Pages 253-255
• Plugs: Pages 225-228
FMVSS:
• P2
3051A
3051
3050
3050A
• Unique combination of colored LEDs with clear lens draws attention to lamp only when lit
• Electronics completely sealed in epoxy to resist corrosion & moisture
• Standard PL-10 connection
• Lower power draw, allowing more power for other vehicle requirements
• Not suitable for PC requirements
3050
Red lamp
3050A Yellow lamp
3051 Red lamp w/clear lens
3051A Yellow lamp w/clear lens
3070 Red lamp w/gray flange
.195 screw hole diameter
Flush Mount
Surface Mount
2.610 bolt hole diameter
3053
Integral flange, lamp, red
3053A Integral flange, lamp, yellow
3058 Single diode, lamp, red
3058A Single diode, lamp, yellow
3053
3053A
3058
3058A
3070A Yellow lamp w/gray flange
3071 Red lamp w/clear lens & gray flange
3071A Yellow lamp w/clear lens & gray flange
