Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
63
M/C
LED
30
®
Series
Low Profile
2” Sealed
2 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 0.05 amp
Kit Components:
30070R/Y grommet kits:
1 - 30270R/Y lamp
1 - 30700 grommet
1 - 93745 plug
30071R/Y gray flange kits
1 - 30272R/Y lamp & flange
1 - 93745 plug
Recommended Accessories:
• Mounting: Pages 253-255
• Plugs: Pages 225-228
FMVSS:
• P2, P3
1.70
2.92
2.24
1.70
1.50
2.92
2.24
1.50
LED
30
®
Series
High Profile
PC Rated
2” Sealed
8 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, 0.10 amp
Kit Components:
30075R/Y grommet kits:
1 - 30275R/Y lamp
1 - 30700 grommet
1 - 94964 plug
30080R/Y gray flange kits:
1 - 30279R/Y lamp & flange
1 - 94964 plug
30085R/Y grommet kits:
1 - 30375R/Y lamp
1 - 30700 grommet
1 - 93745 - plug
30090 Y gray flange kits:
1 - 30379R/Y lamp & flange
1 - 93745 plug
Recommended Accessories:
• Mounting: Pages 253-255
• Plugs: Pages 225-228
FMVSS:
• P2, P3, PC
• LEDs have no filament, therefore are not
susceptible to shock & vibration
• Less current draw, resulting in increased
battery & alternator life while allowing more
power for other vehicle requirements
• SAE PC rated for combination clearance/
marker applications
LED Lamps
30375R Red
30375Y Yellow
LED Lamp w/ABS logo
30282Y Yellow
LED Lamp & Gray Flange
30379R Red
30379Y Yellow
LED Lamp w/ABS logo
30281Y Yellow
LED Grommet Kits
30075R Red
30075Y Yellow
LED Gray Flange Kits
30080R Red
30080Y Yellow
LED Lamp
30275R Red
30275Y Yellow
LED Lamp w/ABS logo
30264Y Yellow
LED Lamp & Gray Flange
30279R Red
30279Y Yellow
LED Lamp w/ABS logo
30269Y Yellow
LED Grommet Kits
30085R Red
30085Y Yellow
LED Gray Flange Kits
30090Y Yellow
.69
2.01
.375
2.93
• Low profile design reduces damage from tree
limbs & dock seals
• Epoxy encapsulated electronics prevent
damage from moisture & corrosion
• Low current draw
• Resistant to shock & vibration
• Not recommended for PC applications
LED Grommet Kits
30070R Red
30070Y Yellow
LED Gray Flange Kits
30071R Red
30071Y Yellow
LED Lamp
30270R Red
30270Y Yellow
LED Lamp & Gray Flange
30272R Red
30272Y Yellow
LED Lamp & Black Flange
30277R Red
30277Y Yellow
