FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
6
LED Lamp Only
44302R Red, 6 diode
44982R Red, 6 diode, diamond shell
44202R Red, 42 diode
44882R Red, 42 diode, diamond shell
44253R Red, 17 diode, 24 volt
1.74
5.50
1.74
4.35
• U.S. Patent #6654172 & U.S. Registered TM #3483147
• Less current draw, resulting in increased battery & alternator life while allowing
more power for other vehicle requirements
• Faster illumination offers significant safety benefit for following drivers to react
quicker, resulting in an average distance of 3’ for every 10 mph
• LEDs have no filament, therefore are extremely resistant to shock & vibration
• Flange mounts are permanently affixed to lamp
6 Diode Pattern
42 Diode Pattern
17 Diode Pattern
See Page 2
LED
Super 44
®
Stop/Turn/Tail
6, 17, & 42
Diode Pattern
Material:
• Polycarbonate or acrylic lens
(diamond shell),
housing & flange
• PVC grommet
• 16 gauge wire
Light Source:
• LED
• 6 diode designed at 14 V,
.03/.3 A
• 42 diode designed at 14 V,
.1/.5 A
• 17 diode designed at 28 V,
.25/.5 A
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• I6, P2,S2, (3)T
Grommet Kits
44030R Red, 6 diode
44092R Red, 6 diode, diamond shell
44002R Red, 42 diode
Kits include lamp, 40700 grommet &
94706 adapter
Gray Flange Kits
44032R Red, 6 diode
44022R Red, 42 diode
Kits include lamp w/flange & 94706 adapter
Black Flange Kits
44036R Red, 6 diode
44026R Red, 42 diode
Kits include lamp w/flange & 94706 adapter
White Flange Kits
44038R Red, 6 diode
Kits include lamp w/flange & 94706 adapter
Lamp & Gray Flange
44322R Red, 6 diode
44983R Red, 6 diode, diamond shell
44222R Red, 42 diode
44883R Red, 42 diode, diamond shell
Lamp & Black Flange
44326R Red, 6 diode
44986R Red, 6 diode, diamond shell
44226R Red, 42 diode
44266R Red, 17 diode, 24 volt
Lamp & White Flange
44328R Red, 6 diode
44988R Red, 6 diode, diamond shell
