11 / 348
FRONT & REAR LIGHTING
UNI
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
9
4051A
4050A
4051
4050
LED
Stop/Turn/Tail
& Front/Park/Turn
24 Diode Pattern
Material:
• Polycarbonate lens &
housing
Light Source:
• LED
• 12 V lamp designed at
13.5 V, .030/.380 A
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• Red - I6,P2,S2, (3)T
• Yellow - I6,P2,P
1.51
4.00
.62
4.31
1.00
• Uses standard right Angle connection
• Unique LED array displays a full pattern light output design
• Epoxy encapsulated electronics prevents damage from
moisture & corrosion
4050
Red lamp
4051 Red lamp w/clear lens
4050A Yellow lamp
4051A Yellow lamp w/clear lens
5.45”
1.80”
0.11”
4.48”
5”
1.80”
0.11”
4.48”
5.45”
1.80”
0.11”
4.48”
LED
Stop/Turn/Tail
Integral Flange
24 Diode Pattern
Material:
• Polycarbonate lens
& housing
Light Source:
• LED
• 24 Diodes
• 12 V, 0.01/0.138 A
FMVSS:
• FMVSS P2; FMVSS S2;
FMVSS I6; FMVSS T
• Housing and flange are molded together to form one piece
• Uses standard right angle PL-3 connection
• Designed with impact-resistant polycarbonate material
• LEDs do not have a filament, therefore are not susceptible to shock and vibration
damage major cause of failure for lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• When properly mounted, exceeds FMVSS DOT requirements for S/T/T and F/P/T
• Lamps come with Truck-Lite 2-Year Limited Warranty
4053 Integral flange, lamp, red
