FRONT & REAR LIGHTING
UNI
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
7
See Page 2
1.74
4.35
1.74
5.50
1.74
4.35
1.74
5.50
1.74
5.50
• U.S. Patent #6654172 & U.S. Registered TM #3483147
• Hardwired design results in decreased depth compared to integral plug
versions, allowing for mounting in confined spaces
• LEDs have no filament, therefore are extremely resistantto shock &
vibration, a major cause of failure for lamps with incandescent bulbs
• Less current draw, resulting in increased battery & alternator life while
allowing more power for other vehicle requirements
• Faster illumination offers significant safety benefit for following drivers to
react quicker, resulting in an average distance of 3’ for every 10 m.p.h.
1.74
4.35
1.74
5.50
1.74
4.35
1.74
5.50
1.74
4.35
1.74
5.50
Hardwired w/Blunt
Cut, Lamp Only
44350R Red
Gray Flange Mount
44362R Red
White Flange Mount
44356R Red
Hardwired w/PL-3
Adapter, Lamp Only
44351R Red
44960R Red,
diamond
shell
Gray Flange Mount
44363R Red
Hardwired w/Mate for
Fit ’N Forget®, Lamp Only
44353R Red
44972R Red,
diamond shell
Gray Flange Mount
44365R Red
White Flange Mount
44359R Red
1.74
4.35
1.74
5.50
Hardwired
w/Male Pin Adapter
Lamp Only
44355R Red
Gray Flange Mount
44367R Red
White Flange Mount
44980R Red
Gray Flange Mount
44957R Red,
diamond
shell
White Flange Mount
44360R Red
LED
Super 44
®
Stop, Turn & Tail
6 Diode Pattern
Hardwired
Material:
• Polycarbonate lens,
housing & flange
• 16 gauge wire
Light Source:
• LED
• Designed at 14 V, .03/.3 A
Recommended Accessories:
• Mounting: Pages 259-261
FMVSS:
• I6, P2,S2, (3)T
