FRONT & REAR LIGHTING
UNI
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
11
• Uniquely designed shock-mount
extends lamp life
• Diamond Shell versions available
for additional protection
• Available with or without reflectorized lens
Super 40
®
Stop/Turn/Tail &
Front/Park/Turn
4” Sealed
Material:
• Polycarbonate or acrylic
lens & housing
• ABS flange
• PVC grommet
• 16 gauge wire
Light Source:
• Heavy duty bulb
• Designed at 13.5 V,
2.16/.47 A, 32/2 cp
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• Non-reflectorized
• Red - I6P2,S2,T
• Yellow - I6,P2,P,O,T,C,W
Lamp & Gray Flange
40258R Red
40258Y Yellow
Lamp & Black Flange
40259R Red
2.09
5.50
Super 40 Lamps
40242R Red
40248R Red reflectorized*
40242Y Yellow
2.11
4.31
*8 Sq. in. (illuminating) stop/turn lens area for vehicles
under 80 in. wide. Meets reflex, tail or clearance function
for vehicles over 80 in. wide.
40
®
Series Stop/Turn/Tail
& Front/Park/Turn
4” Sealed
Material:
• Polycarbonate lens & housing
• ABS flange
• PVC grommet
• 16 gauge wire
• Light Source:
• Heavy duty dual filament bulb
• 12 V designed at 12.8 V, 2.1/.48 A, 32/2 cp,
24 V designed at 28 V, .93/.34 A, 32/6 cp
Kit Components:
40002R/Y grommet kits:
1 - 40202R/Y 12v lamp
1 - 40700 grommet
1 - 94993 right angle PL3
40009R/Y grommet kits:
1 - 40209R/Y 24v lamp
1 - 40700 grommet
1 - 94993 right angle PL3
40015R grommet kit:
1 - 40215R lamp
1 - 40700 grommet
1 - 94993 right angle PL3
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• Non-reflectorized
• Red - I6,P2,S2,T
• Yellow - I6P2,P,O,T,C,W
• Heavy duty bulb last longer
• Uniquely designed shock-mount extends lamp life
• Available with or without reflectorized lens
• Flush mount grommets are designed for mounting in a 4-1/2” hole
Lamp & Black Flange
40233R Red
40233Y Yellow
2.15
5.50
Model 40 Lamps
40202R Red
40202Y Yellow
40209R Red, 24v
40209Y Yellow, 24v
40215R Red, reflectorized*
40232R Red, 24v,
reflectorized*
2.11
4.31
Grommet Kits:
40002R Red
40002Y Yellow
40009R Red, 24v
40009Y Yellow, 24v
40015R Red,reflectorized*
*8 Sq. in. (illuminating) stop/turn lens area for
vehicles under 80 in. wide. Meets reflex, tail or
clearance function for vehicles over 80 in. wide.
See Pages 6 - 10
See Page 2
