14 / 348
FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
12
Male Pin 40
Stop/Turn/Tail
Sealed
Material:
• Polycarbonate lens &
housing
• PVC grommet
• 16 gauge wire
Light Source:
• Heavy duty dual filament
cartridge bulb
• Designed at 13.5 V,
2.16/.47 A, 32/2 cp
Kit Components:
49002R grommet kit:
1 - 49202R lamp
1 - 40700 grommet
1 - 96107 plug
Recommended Accessories:
• Mounting: Pages 259-261
FMVSS:
• I6,P2,S2,T
2.06
4.31
• Shock mount absorbs road shock & vibration
• Welded connections eliminate failures caused by arcing
• Replaces Grote® #53102
49002R Red, grommet kit
49202R Red lamp
40006R
40
®
Series
Stop/Turn/Tail &
Front/Park/Turn
Clear Back, Sealed
Material:
• Polycarbonate lens & housing
• PVC grommet
• 16 gauge wire
Light Source:
• Designed at 12.8 V,
2.1/.48 A
• Dual filament bulb
rated at 32/2 cp
Kit Components:
40006R grommet kit:
1 - 40206R lamp
1 - 40700 grommet
1 - 94993 plug
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• I6,P2,P
• Features clear back housing
• Not recommended for clearance marker applications• Grommet kit features flush mounting in a 4 1/2” hole
2.11
4.31
40006R Red, grommet kit
40206R Red lamp
40206Y Yellow lamp
