FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
8
44
®
Series
Security Grommet
For Flanged Lamps
Material:
• PVC grommet
44
®
Series
Security Flange
For Non-Flanged
Lamps
Material:
• Stainless steel ring
• EPDM mounting gasket
Kit Components:
44034R kit:
1 - 44334R lamp & security
flange
1 - 94706 adapter plug
Replacement Parts:
• 97334 - flange for 7 & 10
gauge applications
• 97337 - flange for 8 gauge
applications
• Helps protect LED lamp from theft by locking them in place
• Snap-and-go installation greatly reduces mounting time & eliminates
need for screw holes or mounting screws
• Stainless steel construction makes for a chrome-like, shiny appearance
• Fits Truck-Lite Super 44® 6 diode LED lamps
• Eliminates ability to remove lamp from outside of vehicle
• Access to back of mounting application required to remove lamp
• With “Pull-Through” design, flanged lamp is partially installed from behind & mounting
lip is pulled through on front of mounting application
• PVC construction allows lamp to fall back into mounting box upon great impact,
reducing chance of damage
• Easily mounts over any Truck-Lite Super 44® series 4” flanged LED lamp
Recommended hole sizes for
grommet installation:
Plate Thickness Hole Size
1/16”
4.47”
1/8”
4.50”
3/16”
4.50”
1/4”
4.53”
3/8”
4.56”
.90
5.43
6.00
5.34
44710 Security grommet (lamp sold separately)
44334R Lamp & flange kit, 7, 8 & 10 gauge
44034R Lamp, pigtail & flange kit, 7, 8 & 10 gauge
