81 / 348
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
79
M/C
Slimline
Bulb Replaceable
Material:
• Polycarbonate lens &
housing
• 18 gauge wire
Light Source:
• Bulb: #193
Replacement Parts:
• 9082 red lens
FMVSS:
• P2,PC
Signal-Stat
®
4.430
1.560
1.220
3.000
4.000
1.180
1.030
4.000
3.000
1.180
1.030
26 Series
Bulb Replaceable
Material:
• Acrylic lens
• Rubber housing
Light Source:
• Bulbs: Two #194
wedge base
Replacement Parts:
• 99051R red lens
• 99051Y yellow lens
FMVSS:
• P2
• Features snap-in lens
• Rubber housing provides additional protection against
shock & vibration
• Hardwired design eliminates pin corrosion
.215 screw hole diameter
26310R Red lamp
26310Y Yellow lamp
26 Series
Bulb Replaceable
Material:
• Polycarbonate lens
• ABS housing
Light Source:
• Bulbs: Two #194 wedge base
Replacement Parts:
• 99050R red lens
• 99050Y yellow lens
FMVSS:
• P2
.218 screw hole diameter
• Features snap-on lens for quick and easy bulb replacement
• Hardwired design eliminates pin corrosion
26312R Red lamp
26312Y Yellow lamp
3.00
1.50
1.25
3.50
2.88
.700
1.938
3.505
2.402
7/16"R
4.130
.880
3.030
.125
Rubber Body Mount
Bulb Replaceable
Material:
• Acrylic lens
• Rubber housing
Light Source:
• Bulb: two #1895
FMVSS:
• P2
• Compact styling is ideal
for narrow body channel
mounting
• Hardwired design eliminates
pin corrosion
1506 Red lamp
1506A Yellow lamp
1506W Clear (utility lamp)
Model 14®
Rectangular Sealed
Material:
• Polycarbonate reflectorized
lens & housing
• PVC grommet
Light Source:
• 12v designed at .33 amp,
2 cp
Recommended Accessories
• Plugs: Pages 209-212
• 14700 white grommet
• 14701 black grommet
FMVSS:
• A,P2
14700
14200Y
14200R Red lamp
14200Y Yellow lamp
Grommet Hole Size
lamp
• Features snap-in lamp with
reflector
• Grommets flush mount the lamp
to vehicle
• Not suitable for PC requirements
• Uses standard PL-10 connection
1.00
.75
3.50
3.00
Signal-Stat
®
.220 screw hole
diameter terminal
size .180 diameter
male bullet
• U-Haul and Stoughton Trailer replacement lamp
• “HT” suffix versions have .180” bullet terminal
1520HT Red lamp w/harness terminated
1520AHT Yellow lamp w/harness terminated
1520
1520AHT
