77
M/C
LED
PC Rated
Sealed
8 Diode Pattern
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 12.8v, .12 amp
FMVSS:
• P2
3.0"
2.0"
1.0"
.38"
3.88"
3.0"
2.0"
1.0"
.38"
3.88"
• Popular in owner-operator &
show truck applications
• Hardwired design eliminates
pin corrosion
• SAE PC rated for combination
clearance/marker applications
2674 Red lamp
2674A Yellow lamp
1.125
4.00
2.00
3.00
See page 76
Shock/Mount
Two Bulb Die Cast
Bulb Replaceable
Material:
• Acrylic lens
• Die cast housing
Light Source:
• Bulbs: Two #193
Replacement Parts:
• 9006 red lens & O-ring
• 9006A yellow lens & O-ring
• 9180 O-ring
• 9523 mounting pad
Recommended Accessories:
• Mounting: Page 259
FMVSS:
• P2
• Die cast base with heavy mounting pad
• Shock/Mount for maximum bulb life
• Two bulb design – if one burns out, the other
remains lighted
• Lamp meets requirements with only one bulb
• Hardwired design with blunt cut ends
• Replaces Truck-Lite 26303 series
1203 Red lamp
1203A Yellow lamp
1203G Green lamp
.218 screw hole diameter
1203G
1203
1203A
1.125
4.00
2.00
3.00
See page 76
Shock/Mount
Two Bulb
Bulb Replaceable
Material:
• Acrylic lens
• Permastat housing
Light Source:
• Bulbs: Two #194
Replacement Parts:
• 9007 red lens
• 9007A yellow lens
• 9007G green lens
• 9007W clear lens
• 9523 mounting pad
Recommended Accessories:
• Mounting: Page 259
FMVSS:
• P2
• Shock/Mount (1213 model) for maximum bulb life
• Two bulb design – if one burns out, the other
remains lit
• Hardwired design with blunt cut ends
• Snap-on lens makes bulb and lens replacement easy
• Lamp meets requirements with only one bulb
• Replaces Truck-Lite 26302 series
1211A
1211 Red lamp
1211A Yellow lamp
1211W Clear (Utility lamp)
1213 Red lamp, shock/mount
1213A Yellow lamp, shock/mount
.218 screw hole diameter
