80
Beehive Design
Bulb Replaceable
Material:
• Acrylic lens & ABS housing
• Aluminum bracket
Light Source:
• Bulb: #67
Replacement Parts:
• 9004 red lens
• 9004A yellow lens
FMVSS:
• P2
LED
Chrome Plated
2 Diode Pattern
Material:
• Acrylic lens
• Chrome plated ABS housing
• 16 gauge 2 wire
Light Source:
• Light Emitting Diodes (LEDs)
FMVSS:
• P2
3.880
5.000
2.250
1.500
3.88"
4.78"
1.38"
2.13"
3.88"
1.38"
2.13"
LED
Narrow Rail
Deflector Mount
PC Rated
Lens Replaceable
4 Diode Pattern
Material:
• Acrylic lens
• Chrome painted steel housing
• Hardwired
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 12.8v, 0.065 amp
FMVSS:
• P2
• Hardwired design eliminates pin corrosion
• Fully protected lens with high guard
• Snap-in lens for easy replacement
2671
Red lamp
2671A Yellow lamp
• SAE PC rated for combination clearance/marker
application
• Hardwired design eliminates pin corrosion
26311R
26313Y
26311R Red, one bulb & die cast
26311Y Yellow, one bulb & die cast
26313R Red, two bulbs & ABS
26313Y Yellow, two bulbs & ABS
26 Series Lamps
Bulb Replaceable
Material:
• Acrylic lens
• Die cast or ABS housing
Light Source:
• Bulbs: #168 wedge base
Replacement Parts:
• 99160Y yellow lens
FMVSS:
• PC
26311R
26313Y
.50
2.25
3.75
.50
2.25
3.75
Signal-Stat
®
• Flush mount design
• Mounting gasket included
• Hardwired design eliminates pin corrosion
2675 Red lamp
2675A Yellow lamp
• Popular boat & utility trailer lamp
• Serves as legal reflector
• when mounted between 15 & 60 inches from ground
level on trailers less than 80” wide
• Hardwired design eliminates pin corrosion
Reflectorized Lamp
Bulb Replaceable
Material:
• Acrylic lens & housing
Light Source:
• Bulb: #194
Replacement Parts:
• 8947 red lens
• 8947A yellow lens
FMVSS:
• A,P2
1570 Red lamp
1570A Yellow lamp
2.09
2.84
2.31
1.00
.25 x .75 stud mount
2.43
1.00
4.56
2.43
1.00
4.56
• High-impact acrylic housing protects against rust
& corrosion
• Rigid right angle bracket
• Snap-on lens allows simple bulb replacement
• Hardwired design eliminates pin corrosion
1001D Red lamp, retail pack
1001AD Yellow lamp, retail pack
