78 / 348
M/C
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
76
.208 3.00
.929 1.70
6.25
2.00
4.75
• Unique dome lens design
• Popular in trailer & body applications
• Hardwired design with molded .180
bullet ends
• Innovative optics design allows for
horizontal mounting
• LEDs have no filament, therefore are
not susceptible to shock & vibration
• Not suitable for PC requirements
26270R Red lamp
26270Y Yellow lamp
LED
26 Series
Dome Lens &
Surface Mount
3 Diode Pattern
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v,0 .05 amp
Recommended Accessories:
• Mounting: Page 259
FMVSS:
• P2
1.50 dia. mounting hole
1.13
4.75
2.00
3.00
LED
26 Series
Sealed
3 Diode Pattern
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, .05 amp
Recommended Accessories:
• Mounting: Page 259
• 97073 lamp gasket
FMVSS:
• P2
• Popular in trailer & body applications
• Hardwired design with blunt cut or molded bullet ends
• Innovative optics design allows for horizontal or vertical mounting
• Not suitable for PC requirements
26250R Red lamp w/.180 molded bullet
26250Y Yellow lamp w/.180 molded bullet
26251R Red lamp, blunt cut
26251Y Yellow lamp, blunt cut
1.50 dia. mounting hole
3.00
1.09
4.05
2.03
LED
Sealed
16 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.5v, .080 amp
Replacement Parts:
• 99238R Red, lens
• 99238Y Yellow, lens
• 99238C clear lens
Recommended Accessories:
• Mounting: Page 259
FMVSS:
• P2
• Hardwired design eliminates pin corrosion
• Encapsulated electronics
• Hardwired design with blunt cut ends
2660
Red lamp
2660A Yellow lamp
2661 Red lamp w/clear lens
2661A Yellow lamp w/clear lens
2660
2660A
2661A
2661
