80 / 348
M/C
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
78
.188 screw hole diameter
Reflex Two Bulb
Bulb Replaceable
Material:
• Acrylic lens
• ABS housing
Light Source:
• Bulbs: Two #193
Replacement Parts:
• 8933 red lens
• 8933A yellow lens
• 9522 mounting pad
FMVSS:
• A,P2
• Serves as a legal reflector
when mounted between 15”
& 60’’ from ground level on
trailers less then 80’’ wide
• Hardwired design eliminates
pin corrosion
Shock/Mount
Extended Lens
Bulb Replaceable
Material:
• Polycarbonate lens &
housing
Light Source:
• Bulbs: Two #193
Replacement Parts:
• 9077 red lens
• 9077A yellow lens
• 9180 O-ring
• 9523 mounting pad
FMVSS:
• P2
1.12
2.00
3.00
4.00
1.12
2.00
3.00
4.00
Signal-Stat
®
Reflex Two Bulb
Bulb Replaceable
Material:
• Acrylic lens
• ABS housing
Light Source:
• Bulbs: Two #193
Replacement Parts:
• 9057 red lens
• 9057A yellow lens
FMVSS:
• A,P2
• SAE Class A reflex reflector snap-on lens
• Hardwired design eliminates pin corrosion
• Serves as a legal reflector when mounted
between 15 & 60 inches from ground level
on trailers less than 80’’ wide
1222
Red lamp
1222A Yellow lamp
1.125
2.00
4.75
5.875
1.125
2.00
4.75
5.875
Signal-Stat
®
• External mounting holes save
installation time
• Hardwired design eliminates pin
corrosion
• Two bulb design – if one burns
out, the other remains litw
1233 Red lamp
1233A Yellow lamp
1.00
2.00
3.00
4.00
1.12
2.00
4.00
3.00
Signal-Stat
®
See page 76
Signal-Stat
®
Shock/Mount
Two Bulb
Bulb Replaceable
Material:
• Acrylic lens
• ABS housing
Light Source:
• Bulbs: Two #193
Replacement Parts:
• 9093 red lens
• 9093A yellow lens
• 9093B blue lens
• 9093G green lens
• 9522 mounting pad
• 97937 gasket
FMVSS:
• P2
• Snap-on lens permits easy bulb & lens
replacement
• Optional mounting gasket available to
improve seal between lamp & body
1259 Red lamp
1259A Yellow lamp
1264 Red lamp
1264A Yellow lamp
5.250
3.620
1.500
2.000
3.18
1.00
3.00
1.12
Signal-Stat
®
26 Series
Armored
Bulb Replaceable
Material:
• Acrylic lens
• Zinc-plated
steel housing
Light Source:
• Bulbs: #1895
FMVSS:
• P2
• Features zinc-plated steel housing
• Hardwired design eliminates pin
corrosion
26315R Red lamp
26315Y Yellow lamp
0.218 screw hole diameter
• Mini lamp features external mounting holes
• Hardwired design eliminates pin corrosion
1507 Red lamp
1507A Yellow lamp
Pee Wee
Bulb Replaceable
Material:
• Polycarbonate lens
• ABS housing
Light Source:
• Bulb: #1895
Replacement Parts:
• 9342 red lens
• 9342A yellow lens
FMVSS:
• P2
