CAMSHAFTS
BRAKE CAMSHAFTS — DRIVE AXLE
FOR MERITOR DRIVE AXLES WITH 16-1/2” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-11581
LH
1-3/16”
Meritor 2210W7667
15-3/32”
E-3993B E-2769HD Induction hardened body.
E-11580
RH
Meritor 2210V7666
E-9681
LH
1-3/16”
Meritor 2210A7671
15-3/16”
E-3993B E-2769HD
E-9682
RH
Meritor 2210Z7670
E-11583
LH
1-3/16”
Meritor 2210E7675
15-5/16”
E-3993B E-2769HD
E-11582
RH
Meritor 2210D7674
E-10306A
LH
1-3/16”
Meritor 2210N7684
15-19/32”
E-3993B E-2769HD
E-10307A
RH
Meritor 2210M7683
E-11639
LH
1-3/16”
Meritor 2210D8220
15-45/64”
E-3993B E-2769HD LX/MX 500 (1-5/8” Bushing Journal)
E-11638
RH
Meritor 2210C8219
E-9683
LH
1-3/16”
Meritor 2210S7689
15-23/32”
E-3993B E-2769HD Tractor, Transit, Truck
E-9684
RH
Meritor 2210R7688
E-11641
LH
1-3/16”
Meritor 2210M8177
15-13/16”
E-11904 E-2769HD LX/MX 500 (1-5/8” Bushing Journal)
E-11640
RH
Meritor 2210L8176
E-11585
LH
1-3/16”
Meritor 2210W7693
15-13/16”
E-3993B E-2769HD
E-11584
RH
Meritor 2210V7692
E-11587
LH
1-3/16”
Meritor 2210A7697
15-61/64”
E-3993B E-2769HD
E-11586
RH
Meritor 2210Z7696
E-11589
LH
1-3/16”
Meritor 2210E7701
16-3/32”
E-3993B E-2769HD
E-11588
RH
Meritor 2210D7700
E-11591
LH
1-3/16”
Meritor 2210S7715
16-29/64”
E-3993B E-2769HD
E-11590
RH
Meritor 2210R7714
E-11593
LH
1-3/16”
Meritor 2210W7719
16-19/32”
E-3993B E-2769HD
E-11592
RH
Meritor 2210V7718
E-11595
LH
1-3/16”
Meritor 2210E7727
16-13/16”
E-3993B E-2769HD
E-11594
RH
Meritor 2210D7726
E-11597
LH
1-3/16”
Meritor 2210J7732
16-61/64”
E-3993B E-2769HD
E-11596
RH
Meritor 2210H7730
E-11599
LH
1-3/16”
Meritor 2210A7749
17-29/64”
E-3993B E-2769HD
E-11598
RH
Meritor 2210Z7748
E-11601
LH
1-3/16”
Meritor 2210S7767
17-61/64”
E-3993B E-2769HD
E-11600
RH
Meritor 2210R7766
E-11603
LH
1-3/16”
Meritor 2210J7784
18-29/64”
E-3993B E-2769HD
E-11602
RH
Meritor 2210H7782
E-11643
LH
1-3/16”
Meritor 2210X8396
18-29/64”
E-11904 E-2769HD LX/MX 500 (1-5/8” Bushing Journal)
E-11642
RH
Meritor 2210W8395
E-11605
LH
1-3/16”
Meritor 2210N7788
18-19/32”
E-3993B E-2769HD
E-11604
RH
Meritor 2210M7787
E-11645
LH
1-3/16”
Meritor 2210F8404
20-61/64”
E-11904 E-2769HD LX/MX 500 (1-5/8” Bushing Journal)
E-11644
RH
Meritor 2210E8403
Extended service camshafts CAN be used in place of standard camshafts.
Standard camshafts CANNOT be used in place of extended service camshafts when sing Extended service shoes and/or linings.
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
