CAMSHAFTS
BRAKE CAMSHAFTS — DRIVE AXLE
FOR MERITOR DRIVE AXLES WITH 16-1/2” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-11563
LH
1-3/16”
Meritor 2210Q7583
12-13/16”
E-3993B E-2769HD
E-11562
RH
Meritor 2210P7582
E-9669
LH
1-3/16”
Meritor 2210U7587
12-15/16”
E-3993B E-2769HD
E-9670
RH
Meritor 2210T7586
E-11627
LH
1-3/16”
Meritor 2210V8394
12-61/64”
E-3993B E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11626
RH
Meritor 2210U8393
E-11565
LH
1-3/16”
Meritor 2210Y7591
13-3/32”
E-3993B E-2769HD
E-11564
RH
Meritor 2210X7590
E-11629
LH
1-3/16”
Meritor 2210M8333
13-13/64”
E-3993B E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11628
RH
Meritor 2210L8332
E-9671
LH
1-3/16”
Meritor 2210A6995
13-7/32”
E-3993B E-2769HD
E-9672
RH
Meritor 2210Z6994
E-9673A
LH
1-3/16”
Meritor 2210L7838
13-7/16”
E-9080
E-2769HD Heat Treated Body
E-9674A
RH
Meritor 2210K7837
E-11631
LH
1-3/16”
Meritor 2210X8266
13-29/64”
E-11904 E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11630
RH
Meritor 2210W8265
E-11569
LH
1-3/16”
Meritor 2210Q7609
13-19/32”
E-3993B E-2769HD
E-11568
RH
Meritor 2210P7608
E-4910A
LH
1-3/16”
Meritor 2210T5454
13-45/64”
E-3993B E-2769HD
E-4911A
RH
Meritor 2210S5453
E-11571
LH
1-3/16”
Meritor 2210A7619
13-13/16”
E-3993B E-2769HD
E-11570
RH
Meritor 2210Z7618
E-9675
LH
1-3/16”
Meritor 2210Q6985
14-3/32”
E-3993B E-2769HD
E-9676
RH
Meritor 2210P6984
E-11573
LH
1-3/16”
Meritor 2210S7637
14-5/16”
E-3993B E-2769HD
E-11572
RH
Meritor 2210R7636
E-11633
LH
1-3/16”
Meritor 2210V8342
14-37/64”
E-11904 E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11632
RH
Meritor 2210U8341
E-9677
LH
1-3/16”
Meritor 2210A7645
14-19/32”
E-3993B E-2769HD
E-9678
RH
Meritor 2210M5343
E-11575
LH
1-3/16”
Meritor 2210E7649
14-45/64”
E-3993B E-2769HD
E-11574
RH
Meritor 2210D7648
E-9679
LH
1-3/16”
Meritor 2210J7654
14-3/4”
E-3993B E-2769HD
E-9680
RH
Meritor 2210H7652
E-11577
LH
1-3/16”
Meritor 2210Q7661
14-61/64”
E-3993B E-2769HD
E-11576
RH
Meritor 2210P7660
E-11579
LH
1-3/16”
Meritor 2210U7665
15-3/32”
E-3993B E-2769HD
E-11578
RH
Meritor 2210T7664
Extended service camshafts CAN be used in place of standard camshafts.
Standard camshafts CANNOT be used in place of extended service camshafts when sing Extended service shoes and/or linings.
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
