CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR SPICER TRAILER AXLES WITH 16-1/2” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
C
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT GENERAL INFORMATION
E-9725
LH
1-3/8”
Dana/Spicer M16WK104-10
17-3/8” 1-5/8” 2-7/32” E-2287 E-2769HD
E-9726
RH
Dana/Spicer M16WK105-10
E-3854
LH
1-3/8”
Dana/Spicer M16WK104-17
20-3/8” 1-5/8” 2-7/32” E-2287 E-2769HD Standard length
E-3855
RH
Dana/Spicer M16WK105-17
E-6884
LH
1-3/8”
Dana/Spicer 16656
Dana/Spicer M16WK104-23
Meritor R607189
22-7/8” 1-5/8” 2-7/32” E-2287 E-2769HD
E-6885
RH
Dana/Spicer 16655
Dana/Spicer M16WK105-23
Meritor R607190
E-3856
LH
1-3/8”
Dana/Spicer M16WK104-25
23-7/16” 1-5/8” 2-7/32” E-2287 E-2769HD
Longer length for Air Ride
suspensions
E-3857
RH
Dana/Spicer M16WK105-25
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
