CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR SPICER (HAYES DANA) TRAILER AXLES WITH 16-1/2” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9709
LH
1-3/8”
Dana/Spicer M16WK102-5
Std. Forge 202100157L
15-5/8” 2-7/32”
E-2287
Check
Application
E-9710
RH
Dana/Spicer M16WK103-5
Std. Forge 202100157R
E-7217
LH
1-3/8”
26-1/4” 2-7/32”
E-7218
RH
E-7219
LH
1-3/8”
26-1/2” 2-7/32”
E-7220
RH
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
