Copyright © 2015 KIC LLC
Assembly PN
Description
Drum PN
3.34
4.87
7.06
11.25
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.43
6.50
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub (2Gen) w/ 11.25" Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
1025 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
42 lbs.
001-00225
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" XHD Drum Bal
54261-018
16.50 7.60
8.78 10.59
M22 x 1.5
2.65
9.79
168
0.80
PRT-00117
001-00225L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" XHD Drum Bal
54261-018
16.50 7.60
8.78 10.59
M22 x 1.5
3.50
9.79
169
0.80
PRT-00118
001-01000
Hub Pilot, M22 x 3.97 Stud, 16.5 x 5" Drum Bal
54257-018
16.50 5.50
8.78
8.56
M22 x 1.5
2.69
7.79
140
0.77
PRT-00117
001-01000L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 5" Drum Bal
54257-018
16.50 5.50
8.78
8.56
M22 x 1.5
3.54
7.79
141
0.77
PRT-00118
001-01001
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
2.65
10.51
167
0.90
PRT-00117
001-01001L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 8-5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
3.50
10.51
168
0.90
PRT-00118
001-01025
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
2.64
9.79
151
0.83
PRT-00117
001-01025L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
3.46
9.79
152
0.83
PRT-00118
001-01026
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 RH
1.41
9.79
150
0.83
PRT-01292
RH
001-01026L
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 RH
1.82
9.79
151
0.83
PRT-01294
RH
001-01027
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 LH
1.41
9.79
150
0.83
PRT-01293
LH
001-01027L
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 LH
1.82
9.79
151
0.83
PRT-01295
LH
