Assembly PN
Description
Drum PN
3.34
4.86
7.06
8.75
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.32
6.39
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 8.75" Dia. Bolt Circle. Uses Inboard Drum - Shoulder Stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
1051 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
44 lbs.
001-10511
Stud Pilot, 3/4-16 RH 12.25" x 7.5" Drum
53039-01
12.25 8.31
7.13 10.47
3/4-16 RH
1.40
10.56
118
0.78
PRT-00874
RH
001-10512
Stud Pilot, 3/4-16 LH 12.25" x 7.5" Drum
53039-01
12.25 8.31
7.13 10.47
3/4-16 LH
1.40
10.56
118
0.78
PRT-00875
LH
Option "T" - ABS Tone Ring
6.77
PRT-00981
80-Tooth Tone Ring
Part Number
Description
Pitch Diameter
