KIC Hub & Drum Assembly Part Numbering System
Notes
: This catalog is divided into sections by axle spindle type. Each hub is listed by the
hub casting (which determines bolt circle, bearing spacing etc.) Option codes are listed below.
For options or configurations not listed here, please contact KIC Engineering or your local KIC
distributor.
Example: 001-01025LTN
“N Spindle Configuration, 1025 Series Hub Cast-
ing with 4.79” M22 Studs, Tone Ring, 10 ea. 22mm
Flange Nuts Installed, Assembled with Drum”
Example: 001-75000TH
“N Spindle Configuration, 75000 Series Spoke Wheel
Casting with ABS Tone Ring, Rim Clamps, Nuts & Spac-
er Band, Assembled with Drum
Icon Legend
Assembly is available with
Stud Piloted
(Ball Seat) mounting
Assembly is available with
Hub Piloted
(Unimount) mounting
Cast Spoke
Wheel Assembly
ABS Ready
(Machined for ABS tone ring)
Assembly available with
Balanced
drum (20 in.oz. std.)
Interchange and competitors’ design information is based on the best information available at the time of publica-
tion and is to be used as a guide only. Although every care has been taken in order to ensure the accuracy of these
interchanges, KIC does not assume any liability for errors, changes, omissions or for harm resulting therefrom. It
is recommended that all parts be thoroughly checked for proper form, fit and function prior to installation and usage
to determine interchangeability.
Hub & Rotor Assembly
KIC Hub & Drum Assembly Nomenclature
Number
SAE Config.
Outer Bearing Inner Bearing
001
N
HM212011 HM218210
002
FF/FG
3720
HM212011
Hub Series
003
FC/FD
3525
39520
1025
004
P
HM518410 HM518410
005
FL
552A
6420
SUFFIX
Description
Application
006
K30/A26
742
752
B
Balanced Assembly (When not standard)
Disc/Spk
007
A45
6535
772
F
Fill Port with SAE Plug
Disc/Spk
008
C-22/ROR Y33213
HM218210
G
Bearing Cones Included
Disc/Spk
009
L-Series
39520
47620
H
Rim Clamps, Nuts & Spacer Band
Spoke
010
R-Series
572
592A
K
Rim Clamps & Nuts Only
Spoke
011
FC
25820
JM207010
L
Studs for Aluminum Wheels
Disc
012
3820
39520
N
Fasteners Installed (in Lieu of Shipping Nuts)
Disc
013
D10
25523
28920
T
ABS Tone Ring
Disc/Spk
014
A65
6535
892
X
Extra-Long Studs
Disc
PRT
Part only - No Assemblies
Y
General/Hyatt® Bearing Cups
Disc/Spk
SVC
Z
Stemco
®
Platinum Performance System
TM
Bearing Cups Disc/Spk
HUB
CST
Casting Only
Bearing Combination
Hub Machined with Cups Only
Hub Machined with Cups & Studs (No Drum)
