Hub Series listed by SAE Designation
Prefix
Hub Series
Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer
Cone
Catalog
Page
001
1002 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001
1006 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
17
001
1025 Series
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001
1051 Series
Ductile Iron 10 stud hub w/ 8.75” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
20
001
2027 Series
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
21
001
2540 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
22
001
7000 Series
Ductile Iron 3-spoke 15”
N HM218210
HM218248
HM212011
HM212049
23
001
75000 Series
Ductile Iron 5-spoke 20”
N HM218210
HM218248
HM212011
HM212049
24
001
75207 Series
Ductile Iron 5-spoke 20”
N HM218210
HM218248
HM212011
HM212049
25
001
76227 Series
Ductile Iron 6-spoke 22”
N HM218210
HM218248
HM212011
HM212049
26
002
137 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002
200 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
30
002
237 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
28
004
40103 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
31
004
40110 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
32
004
40130 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004
40310 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
34
004
41043 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004
41045 Series
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
36
005
51005 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FL
6420
6461A
552A
555S
38
