Assembly Part Number Index
Prefix
Hub Series
Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer
Cone
Catalog
Page
006
2133 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
39
006
2134 Series
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
K30
752
759
742
740
40
007
9518 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
W (A45)
772
787
6535
6580
41
011
4000 Series
Ductile Iron 6 stud hub w/ 8.07” Dia Bolt Circle. Uses Outboard
Drum - Clipped Head Stud
I80 (FC) JM207010
JM207049A
25820
25877
42
011
4100 Series
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Rotor -
Serrated stud
I80 (FC) JM207010
JM207049A
25820
25877
43
012
5010 Series
Ductile Iron 6 stud hub w/ 205.05mm Dia. Bolt Circle, Uses Out-
board Drum - Serrated stud
N/A
39520
39581
3820
3877
44
012
5110 Series
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N/A
39520
39581
3820
3877
45
014
9442 Series
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
A65
892
896
6535
6580
46
Hub Series Index by SAE Designation
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer Cone
Catalog
Page
001-00103
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00103L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00104
Hub Pilot, M22 x 3.70 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00133
Hub Pilot, M22 x 3.97 Stud, 12.25 x 7.5” Drum
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
21
001-00133L Hub Pilot, M22 x 4.82 Stud, 12.25 x 7.5” Drum
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
21
001-00225
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” XHD Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-00225L Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” XHD Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01000
Hub Pilot, M22 x 3.97 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01000L Hub Pilot, M22 x 4.82 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01001
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
