Hub Dynamic Capacities
NOTE:
Hub dynamic capacity is based on the weight-bearing capacity of the wheel bearings. Non-standard wheel offsets or special
applications may affect the weight-bearing capacity of a hub.
Please consult with KIC customer service and wheel supplier when using non-standard wheel offsets or with off-highway ap-
plications to determine total weight-bearing capacity of a hub.
KIC Hubs and cast-spoke wheels meet or exceed the following specifications
ASTM A-536 (Grade 65-45-12)- Standard Specification for Ductile Iron Castings
ASTM E-8- Methods of Tension Testing of Metallic Materials
SAE J434 (Grade 64-45-12) - Automotive Ductile (Nodular) Iron Castings
KIC standard brake drums meet or exceed the following specifications:
ASTM A-159 (Grade G3500b) - Standard Specification for Automotive Gray Cast Iron
SAE J431 (G11H20b) - Automotive Gray Iron Castings
KIC 6xxxx brake drums meet or exceed the following specifications:
ASTM A-159 (Grade G3000b) - Standard Specification for Automotive Gray Cast Iron
SAE J431 (G11H18b) - Automotive Gray Iron Castings
KIC material property testing is governed by:
ASTM A-48 - Standard Tensile Specifications for Gray Iron Castings
ASTM E-8 - Standard Test Methods for Tension Testing
ASTM E-10 - Hardness Testing Procedure
ASTM A-247- Microstructure Evaluation Procedure
Ductile & Gray Iron Properties
Prefix
SAE Designation/
Axle End Type
Inner Cup
Inner Cone
Outer Bearing Cup
Outer Bearing Cone
Hub Dynamic
Capacity
001
N
HM218210
HM218248
HM212011
HM212049
12,500 lbs
002
FF/FG
HM212011
HM212049
3720
3782
7,300 lbs
004
P
HM518410
HM518445
HM518410
HM518445
12,500 lbs
005
FL
6420
6461A
552A
555S
10,000 lbs
006
K30
742
740
752
759
15,000 lbs
007
W (A45)
772
787
6535
6580
22,500 lbs
008
C-22/ROR
Y33213
X33213
HM218210
HM218248
12,500 lbs
011
FC
JM207010
JM207049A
25820
25877
4,000 lbs
012
N/A
39520
39581
3820
3877
5,000 lbs
013
L/190
47620
47686
39520
39590
10,500 lbs
014
A65
892
896
6535
6580
32,500 lbs
