Assembly Part Number by Application
Truck/Trailer - Steer Axle
Hub Series Index by SAE Designation
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer Cone
Catalog
Page
002-00138
Stud Pilot, 3/4-16 RH Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00139
Stud Pilot, 3/4-16 LH Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00142
Hub Pilot, M22 x 3.70 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00142L Hub Pilot, M22 x 3.97 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00144
Hub Pilot, M22 x 3.70 Stud, 15 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00144L Hub Pilot, M22 x 3.97 Stud, 15 x 5” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
27
002-00200
Hub Pilot, M22 x 3.70 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
30
002-00200L Hub Pilot, M22 x 3.97 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
30
002-00237
Hub Pilot, M22 x 3.70 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt
FF/FG HM212011
HM212049
3720
3782
28
002-00237L Hub Pilot, M22 x 3.94 Stud, 15 x 4” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FF/FG HM212011
HM212049
3720
3782
28
005-51005L Hub Pilot, M22 x 4.25 Stud, 16.5 x 6” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FL
6420
6461A
552A
555S
38
005-51005X Hub Pilot, M22 x 4.82 Stud, 16.5 x 6” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
FL
6420
6461A
552A
555S
38
011-04000L Hub Pilot M18 x 3.15 Stud, 12.80 x 4” Drum Bal
Ductile Iron 6 stud hub w/ 8.07” Dia Bolt Circle. Uses Outboard
Drum - Clipped Head Stud
I80
(FC)
JM207010
JM207049A
25820
25877
42
011-04100
Hub Pilot M22 x 2.87 Studs, 15” Rotor
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Rotor -
Serrated stud
I80
(FC)
JM207010
JM207049A
25820
25877
43
012-05010L Hub Pilot M18 x 1.5 Stud, 12.8” 4.35” Drum Bal
Ductile Iron 6 stud hub w/ 205.05mm Dia. Bolt Circle, Uses Out-
board Drum - Serrated stud
N/A 39520
39581
3820
3877
44
012-05110L Hub Pilot M22 x 1.5 Stud, 12.8” x 4” Drum Bal
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N/A 39520
39581
3820
3877
45
