Assembly Part Number by Application
Trailer - Disc Wheel
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer
Cone
Catalog
Page
001-00103
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00103L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00104
Hub Pilot, M22 x 3.70 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
16
001-00133
Hub Pilot, M22 x 3.97 Stud, 12.25 x 7.5” Drum
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
21
001-00133L
Hub Pilot, M22 x 4.82 Stud, 12.25 x 7.5” Drum
Ductile Iron 8 stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
21
001-00225
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” XHD Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-00225L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” XHD Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01000
Hub Pilot, M22 x 3.97 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01000L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 5” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01001
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01001L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01025
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01025L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01026
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01026L
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01027
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01027L
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01070
Hub Pilot, M22 x 3.97 Stud, 15.0 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-01070L
Hub Pilot, M22 x 3.97 Stud, 15.0 x 8-5/8” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
