Assembly Part Number by Application
Trailer - Disc Wheel
Assembly PN Assembly Description
Hub Casting Description
SAE
Code
Inner Cup
Inner Cone
Outer Cup
Outer
Cone
Catalog
Page
001-10061
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
17
001-10062
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
17
001-10511
Stud Pilot, 3/4-16 RH 12.25” x 7.5” Drum
Ductile Iron 10 stud hub w/ 8.75” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
20
001-10512
Stud Pilot, 3/4-16 LH 12.25” x 7.5” Drum
Ductile Iron 10 stud hub w/ 8.75” Dia. Bolt Circle. Uses Inboard
Drum - Shoulder Stud
N HM218210
HM218248
HM212011
HM212049
20
001-21025
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
001-21025L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub (2Gen) w/ 11.25” Dia. Bolt Circle. Uses
Outboard Drum - Serrated stud
N HM218210
HM218248
HM212011
HM212049
18
004-00130
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-00130L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-00131
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-00132
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
33
004-01043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01043L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01048
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8 5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-01048L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 8 5/8” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-21043
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-21043L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum Bal
Ductile Iron 10 stud hub w/ 11.25” Dia. Bolt Circle. Uses Outboard
drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
35
004-40103
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
31
004-40103L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
31
004-40110
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7” Drum
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard
Drum - Serrated stud
P HM518410
HM518445
HM518410
HM518445
32
