FLASHERS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
193
1.00
1.14
0.12
1.99
2.05
1.54
1.67
1.00
1.14
0.12
1.99
2.05
1.54
1.67
LED Electronic
Flasher Module
Material:
• Molded glass filled housing
• 16 gauge wire
• Designed for use in automotive and heavy
duty applications• Creates a strobe flash on an LED lamp
• Hard-wired design eliminates pin corrosion
• Features coded wires and epoxy sealed
circuitry for durability and long term use
• Designed to operate in temperature range
-40˚ to +85˚ C
• Operates on 12v or 24v systems
• Maximum current-7 amps
• Flashes 3 times per 1/2 second
97253
LED electronic flasher module
4.62
2.64
1.32
4.08
1.17
4.62
2.64
1.32
4.08
1.17
• Hard-wired allowing alternating flashing of up to 20
LED lamps (10 lamps per side)
• Features color coded wires, epoxy sealed circuitry
and installation instructions
• Operates on 12v or 24v systems
• Maximum 5-amp load
• Flashes 3 times per 1/2 second
LED Alternating
Strobe Flash
Modules
Material:
• Molded glass filled housing
• 16 gauge wire
97235
LED alternating flasher
3.49
1.85
6.00
LED Strobe
Flash Modules
For Super 44
& 60 Lamps
Material:
• Polypropylene housing
• 18 gauge wire
Specifications:
• Rated for loads below 3 amps
• One module required for each
LED lamp
• Operates on 12v or 24v systems
• For use in a flashing circuit with the vehicle
flasher controlling the rate of flashes per minute
• Creates a strobe flash on an LED lamp, with
typical systems at a rate of 480 FPM
• For use with standard three-position male pin
harness and Truck-Lite stop/turn LED lamps
• Features epoxy-sealed circuitry and a sealed
polypropylene housing for durability and long-
term use
• See the Stop, Turn and Tail Lighting section for
the complete line of Super 44 and 60 LED lamps
97251
LED flasher
