FLASHERS
ELE
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
194
1.170
1.320
0.170
2.660
3.120
2.170
2.120
Heavy-Duty Solid State/
Alternating Flashers
2” x 3” Rectangular
Material:
• Die cast aluminum housing
• 14 gauge lead wire
• 18 gauge ground wire
Recommended Accessories:
• 94954 jumper wire
• 97250 adapter bracket
Specifications:
• Operates in temperatures
-40˚F to +145˚F
• Available with or without audible signal
• Meets FMVSS 108 and SAE J590 and
J1054 (alternating)
• Flashers rate 90 FPM
• 97232 = 85 db
• 97233 = 60 db
• For use with both LED and
incandescent products
• Surface mounts with two 1/2”- 6 pan
head screws at 2.12” centers or with
two 4” cable ties (both included)
• Protects against short circuit overloads
with a self-resetting feature
• 97231, 97232 and 97233 rated for loads
below 25 amps or 12, 32 cp bulbs
• 97201 rated for loads below 17 amps
per channel or 8-32/3 cp bulbs
• Optional remote wiring requires 12”
jumper wire (94954)
• 97231, 97232 and 97233 feature folding
bi-polar plug with 11” leads for reverse
polarity operation
• 97201 features three 1/4” tabs and one
1/4” ring with heat-shrink tubing and
12” leads
• 97201 used for wig/wag system
• For interior/cab use only
• Do not expose to moisture or liquid
97201
97231
97201
Heavy-duty alternating non-audible flasher
97231
Heavy-duty non-audible flasher
97232
Heavy-duty audible flasher
97233
Heavy-duty mechanical tone audible flasher
94954
Remote wiring jumper
1.56
3.80
3.34
4.25
1.90
2.80
Heavy-Duty High
Current Flashers
4-1/4” x 3” Rectangular
Material:
• Die cast aluminum housing
• 10 gauge lead wire
• 18 gauge ground wire
Specifications:
• Surface mounts with three
pan head screws
• Operates in temperatures
-40˚F to +145˚F
• Available with or without
audible signal
• Flashes at a rate of 90 fpm
• Meets FMVSS 108 and
SAE J590, J945 and J1054
(alternating)
• For use with both LED and
incandescent products
• Solid-state electronics are totally
encapsulated in polyurethane
for moisture and corrosion protection
• Designed to protect against short circuit
overloads with a self-resetting feature
• 97270 and 97271 rated for loads below
40 amps at 12.8v (20, 32 cp) or below
20 amps at 25.6v
• 97272 rated for loads below 25 amps at
12.8v per channel or below 12.5 amps
at 25.6v per channel
• 97270 and 97271 feature 12” leads with
two 1/4” spade terminals and one 1/4”
ring with heat-shrink tubing
• 97272 features 12” leads with three
1/4” spade terminals and one 1/4” ring
with heat-shrink tubing
• Do not expose to moisture or liquid
97270
97270
Heavy-duty non-audible flasher
97271
Heavy-duty audible flasher
97272
Heavy-duty non-audible alternating flasher
