FLASHERS
ELE
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
196
1.35
1.33
1.33 TWOTERMINAL THREETERMINAL
1.33
Signal-Stat
®
10 Lamp
Electro-Mechanical
Flashers
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• 24v flasher operates at 22v to 30v
• Operates in a temperature range
0˚F to +125˚F
• Meets FMVSS 108 and SAE J590
and J945
• 42 db rating
• Flashes at a rate of 60 to 120 fpm, with first
flash less than 1.5 seconds after start-up
• Bi-polar flasher functions continuously at 13v
for 36 hours with 10-32 cp lamps, 20-amp max
• Uses standard 1/4” male blade terminals
• Features double coil relay with electronic
components
262
12v, 2-terminal
263
12v, 3-terminal
263-4 24v, 3-termina
262
1.75"
.438"
1.063"
1.125"
1.125"
1.75"
.438"
1.063"
1.125"
1.125"
Signal-Stat
®
12 Lamp
Electro-Mechanical
Flashers
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• Operates in a temperature range
-25˚F to +145˚F
• Meets FMVSS 108 and SAE J590
and J945
• Flashes at a rate of 70 to 120 fpm, with first
flash less than 1.3 seconds after startup
• Functions at 13v for 36 continuous hours
with 12-32 cp lamps, 25 amp
• 2-terminal and 3-terminal models available
172
12v, 2-terminal
173
12v, 3-terminal
1.102
2.200
.433
1.770
THREETERMINAL
TWOTERMINAL
X (input)
L(output)
X (input)
P (pilot)
L(output)
Signal-Stat
®
20, 16 and Alternating
10 Lamp Flashers
1” x 1-3/4” Rectangular
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• Operates in a temperature range
-25˚F to +145˚F
• Meets FMVSS 108 and SAE J590
and J945
• Alternating flasher meets FMVSS
108 and SAE J1054
• 50.9 db max rating
• Flashes at a rate of 70 to 120 fpm, with first
flash less than 1.3 seconds after start-up
• Functions at 13v for 36 continuous hours with
16-32 cp lamps at 35 amp max (#182 and
#183), 20-32 cp lamps at 45 amp max (#282
and #283) and 10-32 cp lamps alternating at 25
amp max per side (#286)
• Features ISO relay w/electronic control circuits
282
182
16 lamp, 2-terminal
183
16 lamp, 3-terminal
282
20 lamp, 2-terminal
283
20 lamp, 3-terminal
286
Alternating 10 lamp, 3-terminal
1.50"
1.375"
1.375"
2.313"
Signal-Stat
®
552
552
2.23”
Thermal Flashers
Material:
• Aluminum housing
• Flashes up to three 32 CP bulbs per
side, plus pilot bulb
• Flashes up to six 32 CP bulbs for
hazard warning
• Heavy duty, longer life, variable load
• Flashes up to three 32 CP bulbs per
side, plus pilot bulb (550 only)
• Flashes up to six 32 CP bulbs for
hazard warning
552
12v, 2-terminal
550
12v, 3-terminal w/pilot
