FLASHERS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
195
1.53
.66
2.66
2.76
1.00
.530
1.68
1.29 1.29
Signal-Stat
®
Solid State LED Heavy
Duty Flashers
Material:
• Plastic housing
• 16 gauge wire
Specifications:
• 12v flasher operates at 11v to 15v
• 24v flasher operates at 22v to 30v
• Meets FMVSS 108 and
SAE J590, J945 and J1054
(alternating)
• Non-audible
• For use with LED and incandescent products
• Rated for 42-amp load or twenty 32 cp bulbs
• For use on double and triple trailer
combinations, sanitation vehicles, delivery
and courier vehicles, heavy haulers and
emergency vehicles
• Manufacturers 5-year limited warranty
• Flasher unit includes 11” of wiring for remote
mounting and includes simplified wiring
instructions
• Maintains normal flash rate when used to
flash LED lamps
• Compatible with trailer tow packages
270
12v, 2-terminal
275
12v, 3-terminal w/pilot
276
12v, 3-terminal alternating
270
1.102
2.200
.433
1.770
THREETERMINAL
TWOTERMINAL
X
L(output)
X
P
L(output)
Signal-Stat
®
LED Circuit Flasher
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• Operates in a temperature range
-25˚F to +145˚F
• Meets FMVSS 108 and SAE J590
and J945
• This solid state flasher operates
from 1 milliamp up to 6 amps
– allowing the use of two
incandescent signal lamps with
LED S/T/T lamps
• Solid state timing circuitry
provides reliability
• Size: 1-1/8” W x 1-5/8” H
• Flashes at rate of 90 fpm
285
LED circuit flasher, 2-terminal
3.0"
1.25"
1.75"
2.563"
1.563"
3.0"
1.25"
1.75"
2.563"
1.563"
Signal-Stat
®
Ever-Flash Flashers
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• Operates in a temperature range
-25˚F to +145˚F
• Meets FMVSS 108 and SAE J590
and J945t
• Certification for 16 bulb capacity for hazard warning
• Flashes up to eight 32 CP bulbs per side, plus pilot bulb
• 35-amp capacity @ 12 VDC
• Low profile, only 1-1⁄4” height above terminals
242
12v, 2-terminal
3.0"
1.25"
1.75"
3.0"
1.25"
1.75"
2.563"
1.563"
Signal-Stat
®
Ever-Flash Flashers
Material:
• Plastic housing
Specifications:
• 12v flasher operates at 11v to 15v
• Operates in a temperature range
-25˚F to +145˚F
• Meets FMVSS 108 and SAE
J590 and J945
• Flashes up to five 32 CP bulbs per side, plus
pilot bulb
• Flashes ten 32 CP bulbs for hazard warning
• 25-amp capacity @ 12 VDC
• Low profile, only 1-1⁄4” height above terminals
243
12v, 3-terminal w/pilot
