199 / 348
ELE
FLASHERS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
197
Signal-Stat
®
1.10
1.70
1.50
THREETERMINAL
X (input)
P (pilot)
L(output)
1.10
1.70
1.50
THREETERMINAL
X (input)
P (pilot)
L(output)
6 Lamp
Electro-Mechanical
Flasher
Material:
• Plastic housing
Specifications:
• 12v operates at 11v to 15v
• Meets FMVSS 108 and
SAE J590 and J945
• GM #15607059
• 1988-1992 GM “CK” series truck replacement
• Replacement for Grumman postal vehicles,
Chevrolet Sierra Crewcab and GMC Suburban
and Yukon
• Third prong used for ground function
• 3-6 lamp load capability with outage indication,
12 lamps for hazard warning
• Replaces Tridon #10-424
266
12v, 3-terminal
1.10
1.70
1.50
THREETERMINAL
X (input)
P (pilot)
L(output)
1.10
1.70
1.50
THREETERMINAL
X (input)
P (pilot)
L(output)
Signal-Stat
®
4 Lamp
Electro-Mechanical
Flasher
Material:
• Plastic housing
Specifications:
• 12v operates at 11v to 15v
• Meets FMVSS 108 and
SAE J590 and J945
• GM #15607060
• 1988-1992 Chevrolet and GMC “S/T”
series truck replacement
• Serves as replacement for GMC Jimmy,
Chevrolet Blazer and S-10 pick-ups
• Third prong used for ground function
• 2-4 lamp load capability with outage
indication, 8 for hazard warning
• Replaces Tridon #10-425
1.475
1.375
.475
1.19
1.375
1.475
1.375
.475
1.19
1.375
Signal-Stat
®
264
12v, 3-terminal
Electro-Mechanical
Flasher
Material:
• Plastic housing
Specifications:
• 12v operates at 9 to 15 VDC
• Operates in temperature
range of 0˚ to +125˚F
• Meets FMVSS 108 and SAE
J590 and J945
• Features loud, pleasant audible sound
• Flash rate of 90 +/- 10 FMP with first
flash less than 1.5 seconds after start-up
• Uses standard 1/4” male blade terminals
• Flashes up to three 32 cp bulbs per side
• Maximum load per side is 6.5 amps
• 71db max rating
537A 12v alternating, 3-terminal
Signal-Stat
®
• For use with plug-in flashers or sealed beams
• Can be used with most Signal-Stat flashers
• Nylon housing provides greater durability
• 7” color coded wire leads
• Insulated 16-gauge wire
• For use with 12 or 24v applications
Connectors
Connectors
9183 Flasher/bulb connector, universal
Signal-Stat
®
• Includes 15 amp blade type fuse
• Ring terminal on lead wire
• 7” color coded wire leads
• Insulated 16 gauge wire leads
• For use with 12 or 24v applications
9186 Flasher connector
