MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
262
ACC
• Popular for tanker requirements
• Features stainless steel constructions
• Available in flange or standoff versions
• Designed for 60 series products with grommet mount
• Replaces Signal-Stat 9292S
60731
60730
3.420
7.950
7.240
Flange cover
0.200 screw hole diameter
7.440
7.040
3.010
.200
Grommet cover
0.140 screw hole diameter
Mounting Covers
For 60 Series
Products
Material:
• Polished stainless steel
• Chrome plated plastic
60704
60403
60700
Grommet Mounts
For 60 Series
Products
Material:
• PVC grommet
• Thermal Plastic Rubber
(TPR) grommet
• 16 gauge wire
Kit Components:
60403 grommet kit:
1 - 60700 grommet
1 - 94993 plug
• Flush mounts the 60 series lamps
• Provides lamps with additional shock absorbency
to extend lamp life
• TPR grommet designed for extreme environmental
applications & eliminates outgassing
• Semi-closed back recommended for incandescent lamps
to protect lamp & wiring while allowing heat to escape
• Closed back recommended for Truck-Lite LED products
only & protects against corrosion & stone damage
• Mounts in up to .25 maximum thick plate
flange mount
standoff mount
7.584
3.344
4.250
1.250 radius
1.060
recommended hole size
semi-closed Back
3.34
7.58
2.40
closed Back
• Grommet cover features chrome plated plastics
to enhance appearance of lamps
• Flange cover provides improved theft resistance
of LED lamps
• Two screws required
Mounting Bracket
For 60 Series
Products
Material:
• Stainless steel bracket
visor
1.125
60730
Flange mount
60731
Standoff mount
60403 Mount, kit
60700
Grommet
60708
Grommet, TPR
60704
Closed back
60718
Flange cover, unpolished stainless steel
60719
Flange cover, stainless steel
60703
Grommet cover
60705
Grommet cover w/visor
