MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
258
ACC
19728
19724
19723
4.00
0.52
radius mount
4.120
3.000
1.532
1.457
0.203 screw hole diameter
Aluminum Mount
Lamp Guards
For Model 19
Products
Material:
• Aluminum mount
• Polycarbonate mount
• Designed for additional protection of
Model 19 base mounts
• Aluminum mount designed with
3”center mounting holes
• Polycarbonate mount designed with
3” & 4.8” center mounting holes
• Not suitable for PC requirements
• Optional mounting gasket available
to improve seal between lamp & body
4.100
3.000
.520
1.070
0.200 screw hole diameter
Standard Mount
• Features unique plug-in design for ease of installation
• Low profile extra strength base
• Suitable for PC requirements on a 45˚ angle
• LED & incandescent lamp kits available
19721
Base Mounts
For Model 19
Products
Material:
• Black or gray polycarbonate
• Chrome ABS mount
Recommended Accessories:
• 96904 hot wire
Curved Bracket
4.68” Radius
For Model 19
Products
Material:
• Gray polycarbonate base
Recommended Accessories:
• 96904 hot wire
• Features unique plug-in design for ease of
installation
• Low profile extra strength base
• Suitable for PC requirements on a 45˚ angle
1.820
4.800
3.000
5.320
1.650
.24Diameterx4
0.250 screw hole diameter
Polycarbonate Mount
19723
Gray guard
19724
Aluminum guard
19720
Gray mount
19721
Gray mount & hot wire
19722
Gray mount w/9” radius
19729
Black mount
19726
Black mount & hot wire
19728
Black mount Chrysler #5600370415
19737
Gray mount Chrysler #5600370415
19738
Gray mount w/6.25” radius
19739
Chrome mount & hot wire
19740
Gray mount w/hot wire & .180 male terminal
19750 Bracket
