Rail Mounts
For Model 15
Products
Material:
• ABS mount
• 16 gauge wire
Kit Components:
15412/15413 kits:
1 – 15727 mount
1 – 94924 or 94927 plug
15414 kit:
1 – 15728 mount
1 – 94924 plug
Deflector Mounts
For Model 15
Products
Material:
• ABS mount
• 16 gauge wire
Kit Components:
15401 kit:
1 – 15720 mount
1 – 96904 hot wire
• Flush mount vinyl PVC grommet
• Mounts in panel thickness up to .250”
• Suitable for PC requirements on a
45˚ angle with incandescent lamps
• Replaces Signal-Stat 9362
• High impact plastic construction
• Easy snap-on lamp installation
• Standard 1” mounting holes
• Permanently affixed hot & ground contacts
• Suitable for PC requirements on a 45˚ angle
with incandescent lamps
• Not recommended for use with license or
LED lamps
Grommet Mount
For Model 15
Products
Material:
• PVC grommet
• Extra strength plastic construction
• Features top cut out area on mount #15727 for narrow rail design
• Easy snap-in lamp installation
• Suitable for PC
requirements with incandescent lamps
• Incandescent lamp kits available
1.34
4.12
1.19
4.50
3.330
1.95
.470
1.560
to
1.620
1/2"R
2.940 to
3.000
0.270 screw hole
Standard Mount
Cut Mount
.203 screw hole dia.
15727
15733
15702 Grommet
15720 Mount, gray
15401
Mount kit
15728
Mount, white
15727
Cut mount, white
15733
Mount, gray
15412
Cut mount
15413
Cut mount
15414
Mount
