MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
260
ACC
Steel Mounting
Brackets
For 4” Lamps
Material:
• Painted steel
Mounting Cover
For 4” Mounts
Material:
• Polished stainless steel
• Black powder coated
stainlesssteel
• Chrome plated plastic
1.25
5.81
.146 dia
40705
Grommet Cover
5.625
.
129
0.25 dia
on 4.94
b.c.
Flange Cover
1.25
5.81
.146 dia
40705
Grommet Cover w/visor
6.000
6.960
0.560
0.370Diameterx5
40719 without flange
6.000
4.000
5.815
1.415
40720 with flange
• Designed to enhance appearanceof lamps
• Flange cover offers improved
theft resistance
• Two or three screws required
*Recommended hole sizes for
accepting the 40700 grommet:
Plate Thickness Hole Size
¹⁄₁₆”
4.47”
¹⁄₈”
4.50”
³⁄₁₆”
4.50”
¹⁄₄”
4.53”
³⁄₈”
4.56”
Mounting Grommets
For 4” Lamps
Material:
• PVC grommet
• Thermal Plastic Rubber (TPR
grommet)
• 16 gauge wire
Kit Components:
40403 grommet kit:
1 - 40700 grommet
1 - 94993 plug
6.00
5.34
.61
Security Grommet
40720
• Flush mount 4” diameter lamps in a
4-1/2” hole
• Designed to provide additional shock
absorbency to extend lamp life
• TPR grommet designed for extreme
environmental applications & eliminates
outgassing
5.500
.430
1.040
Standard Grommet
• Features black painted reinforced steel
• Designed with 4-1/2” hole for mounting
4” lamps
• Available with or without flange
44701
Grommet cover
44700
Grommet cover w/visor
44705
Flange cover, stainless steel
44708
Flange cover, mirror finish
44709
Flange cover, black stainless steel
40403 Black, kit
40700 Black
40819 Black, TPR
40701 Gray
40702
White
40703
Brown
44710
Security grommet for
flange mount lamps
40719 Without flange
40720
With flange
40726 With flange, slotted
