MOUNTING
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
259
ACC
4.659
5.281
2.058
1.130
4.659
5.281
2.058
1.130
.230 screw hole diameter
1.500
3.000
4.252
1.681
1.382
1.000
.220
.799
6.000
.125
.305
0.200 screw hole on 5.50 B.C.
Armored Mount
For LED 35
®
Series
Products
Material:
• Aluminum mount
Chrome Guard
For Model 26 Lamps
Material:
• Chrome-plated steel guard
Adapter Ring
For 4” Lamps
Material:
• ABS ring
• Features high impact plastic construction
• Converts 4-3/4” hole to a 4-1/2” hole
• Replaces Signal-Stat 9117
• Features chrome-plated die cast with mounting holes
• Provides additional protection against the elements• Replaces Truck-Lite 26720
Chrome Bezel
26 Series
Material:
• Plateable grade ABS plastic
• Chrome plated
• Extruded aluminum armored mounting
bracket protects individual lamps from
physical damage
• Wiring routed through .65” access hole in
base of mount
6.62"
2.25"
.57"
• Designed to enhance appearance of lamps
• Corrosion resistant chrome plating• Sleek design
• Use with parts 26250R, 26251R, 26270R,
26250Y, 26251Y, 26270Y
35720
50831 Adapter
9179
Lamp guard
35720
Mount
35722
Mount, black
26002
Chrome bezel
